RED2422 is an advanced LED controller IC for high efficiency low-cost LLC converters with bipolar transistors and integrated PFC, intended for LED T8 tube drivers and high frequency CC LED drivers up to 40W.
   Advanced LED Controller IC for high efficiency low-cost LLC converters with bipolar transistors and integrated PFC PSR - +/-5% Primary Side Regulation of LED current and voltage with no flicker 50% duty cycle, variable frequency control of resonant half-bridge  Automatic dead-time control and capacitive mode protection     Protection modes: a.         Overload b.         No-Load c.         Over-temperature Low output capacitance allows live LED connection  Very low output current ripple < 0.5% Small SOT23-6 IC package
Datasheet
    Key Features
    Order Details
     Code RED2422AL-TR7    Package SOT23-6 Tape & Reel
Reference Design  Check Application Notes Check Application Notes Order Order Low Power LED Controller for LLC Converters RED2422
•	RED2422  (387kB)   •	RED2422  (387kB)   •	 40W 1A Low-cost LED driver  (3058kB) •	 40W 1A Low-cost LED driver  (3058kB)       LED Driver ICs •	 30W 750mA LED driver  (1983kB) •	 30W 750mA LED driver  (1983kB) •	 40W 1A Low-cost LED driver  (3058kB) •	 40W 1A Low-cost LED driver  (3058kB) •	 30W 750mA LED driver  (1983kB) •	 30W 750mA LED driver  (1983kB)
