RediSem’s ICs for fluorescent lighting add high performance,
control and protection to the conventional self-oscillating
bipolar transistor circuits used in many ballasts and CFLs.
Our Fluorescent Lighting IC Products
RediSem LLC drivers
have higher efficiency
than flyback converters.
Resonant converter
operation minimizes
losses resulting in lower
component temperatures
and smaller cases. All our
designs have efficiencies
exceeding 90%.
High
Efficiency
Extensive
Control
Long
Lamp Life
Simple
Design
RediSem ICs 2101
and 2201 have
sophisticated in-built
control mechanisms,
including:
- Controlled preheat
current
- Controlled ignition ramp
- Lamp power limit at
high mains
- Capacitive mode
detection
- Automatic dead-time
control
RediSem’s
fluorescent ICs
dramatically improve
lamp life to over 30,000
lamp starts whilst
offering efficient reliable
operation over a wide
range of mains voltages
and temperatures.
Ballasts are fully
protected and shut down
safely at the lamp’s End-
of-Life (EOL).
RediSem has
complete application
designs and
demonstrator units
available for all its ICs.
These production-ready
LLC driver designs come
with full design
infopacks and can be
easily customized and
optimized.
IC ref
Package
Application
- RED2401 - LLC controller IC for CC LED drivers with passive PFC up to 22W
- RED2402 - LLC controller IC for CC LED drivers with passive PFC up to 40W
- RED2421 - Low Power LED Controller for LLC converters up to 22W
- RED2422 - Ultra low-flicker version of RED2402
- RED2431 - Zero-Flicker LED Driver IC
- RED2432 - Zero-Flicker LED Driver IC
- RED2433 - Zero-Flicker LED Driver IC
- RED2501 - LLC controller IC for CC LED drivers with passive PFC up to 45W
- RED2511 - LLC controller IC for CC LED drivers with passive PFC up to 100W
- RED2521 - Ultra low-flicker version of RED2511
- RED2541 - LLC controller IC for CV LED drivers with active or passive PFC up to 300W
- RED2542 - LLC controller IC for CV LED drivers up to 30W
- RED2543 - LLC controller IC for CV LED drivers up to 250W
- RED2601 - LLC controller IC for CC LED drivers up to 300W
- RED2821 - LLC controller IC for dimmable CC LED drivers with active or passive PFC up to 300W
- RED2822 - Resonant controller IC for CC LED drivers up to 250W
- RED2832 - Resonant controller IC for CC LED drivers up to 250W
- RED2833 - Resonant controller IC for CC LED drivers up to 250W
RediSem’s ICs for fluorescent lighting
add high performance, control and
protection to the conventional self-
oscillating bipolar transistor circuits
used in many ballasts and CFLs.
RediSem LLC drivers have higher
efficiency than flyback converters.
Resonant converter operation minimizes
losses resulting in lower component
temperatures and smaller cases. All our
designs have efficiencies exceeding 90%.
RediSem ICs 2101 and 2201 have
sophisticated in-built control mechanisms,
including:
- Controlled preheat current
- Controlled ignition ramp
- Lamp power limit at high mains
- Capacitive mode detection
- Automatic dead-time control
RediSem’s fluorescent ICs dramatically
improve lamp life to over 30,000 lamp starts
whilst offering efficient reliable operation
over a wide range of mains voltages and
temperatures.
Ballasts are fully protected and shut down
safely at the lamp’s End-of-Life (EOL).
RediSem has complete application
designs and demonstrator units available
for all its ICs. These production-ready LLC
driver designs come with full design
infopacks and can be easily customized
and optimized.
